Overview

Want to deploy a bunch of Canaries and have them pre-configured during the deployment? We can do this using the equivalent cloud-init for each of our cloud and virtual platforms:

• AWS and GCP using the user-data of the instance via a cloud-init yaml file. (jump)
• Azure using the json user-data file of the instance via the instance metadata api. (jump)
• Hyper-V using a base64 encoded key-value pair via the Hyper-V VMbus. (jump)
• VMware using Advanced Configuration Parameters available on vSphere and ESXi. (jump)

What can we set during bootstrapping?

All of the cloud and virtual platforms can set:

• Initial profile
• Initial settings
• Network DNS settings
• Network device name

The VMware birds can also set:

• Network IP and netmask
• DHCP enabled or disabled

AWS and GCP Canaries

Both AWS and GCP make use of cloud init directives and require the '#cloud-config' line at the top of the file to work correctly.

#cloud-config

canary_cloud_init:
  autocommission_token: 87b543236c5054706218
  initial_profile: oracle-linux-8
  initial_settings: eyJmdHAuYmFubmVyIjogIlRlc3QgRlRQIGJhbm5lciIsICJmdHAuZW5hYmxlZCI6IHRydWUsICJmdHAucG9ydCI6IDIxfQ==
  network:
    custom_dns: true
    dns1: 1.1.1.1
    dns2: 8.8.8.8
    name: test-cloud-init

where the initial settings is a base64 encoded string for the settings json block defined as

{
    "ftp.banner": "Test FTP banner",
    "ftp.enabled": True,
    "ftp.port": 21
}

Launching a new AWS canary with user-data

Using the AWS cli the user-data can easily be added on by using '--user-data' parameter

For example:

aws ec2 run-instances --image-id <ami-id> --subnet-id <subnet-id> --security-group-ids <security-group-id> --region eu-west-1 --instance-type t3.micro --user-data file://canary_cloud_init.yaml

Launching a new GCP canary with user-data

Using the GCP cli the user-data can be configure using the '--metadata-from-file' parameter.

For example:

gcloud compute instances create DevOpsStaging-1A --machine-type=e2-micro --image=<image-name> --zone=europe-west4-a --network-interface subnet=<subnet-name> --metadata-from-file user-data=canary_cloud_init.yaml

Azure Canaries

Azure canaries are configure using a json formatted user-date file:

{
  "autocommission_token": "87b543236c5054706218",
  "initial_profile": "oracle-linux-8",
  "initial_settings": "eyJmdHAuYmFubmVyIjogIlRlc3QgRlRQIGJhbm5lciIsICJmdHAuZW5hYmxlZCI6IHRydWUsICJmdHAucG9ydCI6IDIxfQ==",
  "network": {
    "name": "test-cloud-init",
    "custom_dns": true,
    "dns1": "1.1.1.1",
    "dns2": "8.8.8.8"
  }
}

where the initial settings is a base64 encoded string for the settings json block defined as

{
    "ftp.banner": "Test FTP banner",
    "ftp.enabled": True,
    "ftp.port": 21
}

Launching a new Azure canary with user-data

Using the Azure cli the user-data can be configure using the '--user-data' parameter.

For example:

az vm create --name DevOpsStaging-1A --resource-group <resource-group-name> --image <image-name> --vnet-name <vmnet-name> --nsg <network-security-group-name> --subnet <subnet-name> --user-data canary_cloud_init.json

Hyper-V Canaries

Hyper-V canaries require the whole file to be a base64 encoded string

eyJhdXRvY29tbWlzc2lvbl90b2tlbiI6ICI4N2I1NDMyMzZjNTA1NDcwNjIxOCIsICJpbml0aWFsX3Byb2ZpbGUiOiAib3JhY2xlLWxpbnV4LTgiLCAiaW5pdGlhbF9zZXR0aW5ncyI6ICJleUptZEhBdVltRnVibVZ5SWpvZ0lsUmxjM1FnUmxSUUlHSmhibTVsY2lJc0lDSm1kSEF1Wlc1aFlteGxaQ0k2SUhSeWRXVXNJQ0ptZEhBdWNHOXlkQ0k2SURJeGZRPT0iLCAibmV0d29yayI6IHsibmFtZSI6ICJ0ZXN0LWNsb3VkLWluaXQiLCAiY3VzdG9tX2RucyI6IHRydWUsICJkbnMxIjogIjEuMS4xLjEiLCAiZG5zMiI6ICI4LjguOC44In19

with the config being defined as

{
  "autocommission_token": "87b543236c5054706218",
  "initial_profile": "oracle-linux-8",
  "initial_settings": "eyJmdHAuYmFubmVyIjogIlRlc3QgRlRQIGJhbm5lciIsICJmdHAuZW5hYmxlZCI6IHRydWUsICJmdHAucG9ydCI6IDIxfQ==",
  "network": {
    "name": "test-cloud-init",
    "custom_dns": true,
    "dns1": "1.1.1.1",
    "dns2": "8.8.8.8"
  }
}

where the initial settings is a base64 encoded string for the settings json block defined as

{
    "ftp.banner": "Test FTP banner",
    "ftp.enabled": True,
    "ftp.port": 21
}

Launching a new Hyper-V canary with user-data

The Hyper-V Canary expects the key of the KVP to be 'UserData'

Note: Do not power on your Canary before configuring the KVP parameters.

The KVP information can be set using a powershell script for example:

# Define variables for the VM name, key, and data
$vmName = "DevOpsStaging-1A"
$keyName = "UserData"
$keyData = "eyJhdXRvY29tbWlzc2lvbl90b2tlbiI6ICI4N2I1NDMyMzZjNTA1NDcwNjIxOCIsICJpbml0aWFsX3Byb2ZpbGUiOiAib3JhY2xlLWxpbnV4LTgiLCAiaW5pdGlhbF9zZXR0aW5ncyI6ICJleUptZEhBdVltRnVibVZ5SWpvZ0lsUmxjM1FnUmxSUUlHSmhibTVsY2lJc0lDSm1kSEF1Wlc1aFlteGxaQ0k2SUhSeWRXVXNJQ0ptZEhBdWNHOXlkQ0k2SURJeGZRPT0iLCAibmV0d29yayI6IHsibmFtZSI6ICJ0ZXN0LWNsb3VkLWluaXQiLCAiY3VzdG9tX2RucyI6IHRydWUsICJkbnMxIjogIjEuMS4xLjEiLCAiZG5zMiI6ICI4LjguOC44In19"

# Get the Virtual System Management Service
$VmMgmt = Get-WmiObject -Namespace root\virtualization\v2 -Class Msvm_VirtualSystemManagementService

# Get the VM object by its name
$vm = Get-WmiObject -Namespace root\virtualization\v2 -Class Msvm_ComputerSystem -Filter "ElementName='$vmName'"

# Create an instance of the KVP Exchange Data Item
$kvpDataItem = ([WMIClass][String]::Format("\\{0}\{1}:{2}", `
    $VmMgmt.ClassPath.Server, `
    $VmMgmt.ClassPath.NamespacePath, `
    "Msvm_KvpExchangeDataItem")).CreateInstance()

# Set the key-value pair
$kvpDataItem.Name = $keyName
$kvpDataItem.Data = $keyData
$kvpDataItem.Source = 0  # Source 0 indicates that the data is from the host to the guest

# Add the KVP to the VM
$VmMgmt.AddKvpItems($vm, $kvpDataItem.PSBase.GetText(1))

# Output the data being set
Write-Output "Key Name: $($kvpDataItem.Name)"
Write-Output "Key Data: $($kvpDataItem.Data)"

VMware Canaries

See the dedicated article for

• Customising VMware Canaries on Deployment using vSphere
• Customising VMware Canaries on Deployment using ESXi
